Lab Facilities
Our lab is fully equipped for conducting noise measurements. Our facilities include reverberation chambers specifically designed for testing the sound transmission loss of partitions and floors. We have three Brüel & Kjær (B&K) data acquisition modules with 3, 12, and 42 input channels, respectively. Our equipment also includes a B&K Impedance Tube (Type 4206), two beamforming systems with wheel arrays supporting 36 and 42 channels, and over 100 B&K microphones ranging in size from 1/8 inch to 1 inch. Additional instrumentation includes tapping machines (Type 3207), a mini shaker (Type 4810), an omnidirectional loudspeaker (B&K Type 4296), sound level meters, amplifiers, accelerometers, and more. Selected equipment photos are presented below.
- B&K 2270 Two-Channel Sound Level Meter / Analyzer
- B&K 2250 Sound Level Meter/Analyzer (1 CH)
- B&K PULSE Type 3560-D Multichannel Portable Data Acquisition Unit (E1083906)
- 7 module slots
- 3038-B 12-CH 25Khz module x3
- 3039-B 6-CH 25Khz module x1
- 7537-A control module
- 2826 power supply
- Bruel and Kjaer Type 3052 [3 Channel] High-frequency 3-channel Input Module
- Bruel and Kjaer Type 3053-B [12 Channel] High-frequency 12-channel Input Module
- Bruel and Kjaer 20kHz Measurement Microphone Type 4951 (~1/4"", Frequency up to 20KHz)
- Bruel and Kjaer Type 4182 Probe Microphone
- W1558-W-004 Beamforming system sliced wheel array for 36 Channel (E1125117)
- Beamforming system sliced wheel array for 42 Channel
- PCB Piezotronics Short-sledge Impulse Hammer (Model 086D20)
- Signal Conditioner, Battery-powered (Model 480E09)
- Brüel & Kjær Type 3207 Tapping Machine / Impact Sound Source
- OmniPower Sound Source | B&K Type 4296
- Brüel & Kjær Type 4206 Impedance Tube Kit
- Bruel & Kjaer Type 3548 Sound Intensity Probe Kit Set (with Mic 4181)
Sound Level Meter / Analyzer
Microphone
Beamforming System
Tapping Machine / Shaker
OmniPower Sound Source
Others
